DISA GOFF ROTARY BLAST MACHINE 72-5-22

Specifications

Model72-5-22
BrandDISA GOFF
TypeVertical Machining Centers
catalogid5845
mfgDISA GOFF
mpn72-5-22
titleDISA GOFF ROTARY BLAST MACHINE 72-5-22
joinSig

Zero? Available Machines

Available Machine # Ez20734

  • Stock#:Ez20734
  • Price:$24,000
  • Year:2006
  • Region:Northeast
  • Condition:Used
Blast Wheel: 15 HP, 12" Diameter, Direct Drive Distance from Main Table to Blast Wheel Opening: 31" 11-1/2" Diameter of the Base of the 5 Rotating Tables Presently there are Fixtures Mounted to these Tables that are 22" Diameter x 13-1/4" High Replaceable Manganese Wear Plates in Blast Area Open Load and Unload Station in the Front and Rear Blast Station with Door Operator Control Panel with Allen Bradley Power Flex 70 PLCs Disa/Goff Dust Collector, Serial No. 2166941-1, Model No. DF02-4 5 HP, Wired 3 Phase, 60 Cycle, 208-460 Volts (4) Cartridge Type Filters with Air Pulse Cleaning and Magnehelic Gauge 10" Diameter Air Intake Duct Discharge Hopper on the Bottom with Lid to Fit a 55 Gallon Drum 7" Diameter Discharge Hole Overall Dimensions: 5-1/2' L x 4' W x 140" H (Standing Up) Machine Overall Dimensions without Dust Collector: 13-1/2' L x 8' W x 178" H
